| Shank Size (SS) | 50 | Body Material | Steel |
| Protruding Length (LPR) | 75 mm | Measurement Type | Metric |
| Connection Diameter Workpiece Side (DCONWS) | 63 mm | Tool Type | BT |
| Connection Size (CSI) | MB63 | Connection Code Machine Side (CCMS) | BT |
| Coolant Supply Property (CSP) | Coolant Thru | Unit | M |
Product Features
| Family Description | MB modular connection system with BT MAS-403 FORM AD taper shanks | COO | Italy |
| Remarks | Verify that the weight of the entire tool assembly does not exceed the machine spindle's carrying capability. |
Shipping Info
Weight per item
4.0200
